Galvanized Gas Ceramic Infrared Burner With Spark Electrode Fit Oven

China Galvanized Gas Ceramic Infrared Burner With Spark Electrode Fit Oven supplier
Galvanized Gas Ceramic Infrared Burner With Spark Electrode Fit Oven supplier Galvanized Gas Ceramic Infrared Burner With Spark Electrode Fit Oven supplier Galvanized Gas Ceramic Infrared Burner With Spark Electrode Fit Oven supplier Galvanized Gas Ceramic Infrared Burner With Spark Electrode Fit Oven supplier

Large Image :  Galvanized Gas Ceramic Infrared Burner With Spark Electrode Fit Oven

Product Details:

Place of Origin: China PRC
Brand Name: KINGRAY
Certification: CE
Model Number: CIB71

Payment & Shipping Terms:

Minimum Order Quantity: 100pcs
Price: Negotiable
Packaging Details: Carton inside, wooden case outside
Delivery Time: 5-7 days
Payment Terms: T/T, Western Union, Paypal, MoneyGram
Supply Ability: 300pcs per week
Contact Now
Detailed Product Description
Burner Shell: Galvanized Plate Inlet Pipe: SS304
Total Size: 710*94*90mm Burning Area: 590*64mm
Heat Output: 20000BTU / 5000KCAL/H Unit Weight: 2700g

Custom Made Galvanized Gas Ceramic Infrared Burner With Spark Electrode For Oven



Advantages:
Saving 30%~50% gas than common gas fire burner
Durable life:≥11000hr
Eco-friendly: CO≤80ppm; NOx≤10ppm; CHx≤50ppm
Naturally aspirated burner, do not need air blower



Function:
Infrared Burner use honeycomb ceramic plates, the gas can premix with air naturallly when burning and ensure burning completely. Thatcan greatly reduce the emission of pollutants. When burning its about 70% energy changes into infrared by the way of radiate. Such infrared wave (Length 2-4um) can be easily absorbed by physical elements and polymer. That infrared wave has strong penetration which can stimulate the resonance of water molecules, evenly penetrate in the depths of the core material is heated, make sure evenly heating, improve the heating quality and drying efficiency etc. gas infrared heating has become a new technology and new trend. It has been widely used in BBQ grill, oven, bbq machine, etc.



Specifications:

Burning Area 590*64mm Net Weight 2700g
Total Size 710*94*90mm Gas Type LPG / NG
Consumption of LPG 0.25kg/hr LPG pressure 2.8-3kpa
Heat Output 5000KCAL / 20000BTU NG pressure 2-2.2kpa
nozzle not with Inlet pipe SS304
protect net with net material  Stainless woven net
application

bbq grill,oven,kebab, shawarma, etc





















Galvanized Gas Ceramic Infrared Burner With Spark Electrode Fit Oven

Galvanized Gas Ceramic Infrared Burner With Spark Electrode Fit Oven

Galvanized Gas Ceramic Infrared Burner With Spark Electrode Fit Oven
