Galvanized Stainless Steel Infrared Gas Burner , Catalytic Ceramic Gas BBQ Infrared Burner

China Galvanized Stainless Steel Infrared Gas Burner , Catalytic Ceramic Gas BBQ Infrared Burner supplier
Galvanized Stainless Steel Infrared Gas Burner , Catalytic Ceramic Gas BBQ Infrared Burner supplier Galvanized Stainless Steel Infrared Gas Burner , Catalytic Ceramic Gas BBQ Infrared Burner supplier Galvanized Stainless Steel Infrared Gas Burner , Catalytic Ceramic Gas BBQ Infrared Burner supplier Galvanized Stainless Steel Infrared Gas Burner , Catalytic Ceramic Gas BBQ Infrared Burner supplier

Large Image :  Galvanized Stainless Steel Infrared Gas Burner , Catalytic Ceramic Gas BBQ Infrared Burner

Product Details:

Place of Origin: China
Brand Name: KINGRAY
Certification: CE
Model Number: EM-33

Payment & Shipping Terms:

Minimum Order Quantity: 100pcs
Price: Negotiable
Packaging Details: Carton Inside, Pallet Or Wooden Case Outside
Delivery Time: 5-10 days
Payment Terms: T/T, Paypal, Western Union
Supply Ability: 3000pcs per month
Contact Now
Detailed Product Description
Burner Box Material: Galvanized Top Side Plate Material: Stainless Steel
Burning Area: 362*62mm Dimension: 443*85*60mm
Consumption LPG (Kg/hr): 0.15kg/hr Lpg Heat Output: 10000BTU
Net Weight: 1.2kgs Gas Type: LPG / NG
Convertion Rate: >90% With Nozzle: Yes
High Light:

infrared catalytic gas burner

,

natural gas grill infrared burner

Galvanized And Stainless Steel Catalytic Ceramic Infrared Gas Burner With Gas Jet Nozzle​



Function:
Infrared Burner takes honeycomb ceramic plates as burner, the gas can premix with air when burning and ensure burning completely. Thatcan greatly reduce the emission of pollutants. When burning its about 70% energy changes into infrared by the way of radiate. Such infrared wave (Length 2-4um) can be easily absorbed by physical elements and polymer. That infrared wave has strong penetration which can stimulate the resonance of water molecules, evenly penetrate in the depths of the core material is heated, make sure evenly heating, improve the heating quality and drying efficiency etc. gas infrared heating has become a new technology and new trend. It has been widely used in many fields, such as BBQ grill, bbq oven, gas infrared oven.



Advantages:
Saving 30%~50% energy than common gas flame burner
Long useful life:≥11000hr
Eco-friendly: CO≤80ppm; NOx≤10ppm; CHx≤50ppm
Naturally aspirated burner, no need of accessories like air blower



Material:
1. Shell: galvanized sheet and stainless steel up stamped plate
2. Radiant part: cordierite ceramics honeycomb plates
3. Up cover: stamped stainless steel



Specifications:

Burning Area 362*62mm Net Weight 1.2kgs
Dimension 443*85*60mm Gas Type LPG / NG
Consumption 0.15kgs/hr LPG LPG pressure 2.8-3kpa
Heat Output 10000BTU NG pressure 2-2.2kpa
Burner Box Material galvanized surface metal Material stainless steel

Galvanized Stainless Steel Infrared Gas Burner , Catalytic Ceramic Gas BBQ Infrared Burner
Galvanized Stainless Steel Infrared Gas Burner , Catalytic Ceramic Gas BBQ Infrared Burner
Galvanized Stainless Steel Infrared Gas Burner , Catalytic Ceramic Gas BBQ Infrared Burner
